China PE Pipe Manufacturers - PE Pipe Suppliers and Factory

Your Professional PE Pipe Supplier

Baoding Lida Plastic Industry Co., Ltd., founded in 1997, is an international plastic products group company integrating R&D, production, sales, service, and import/export operations. It is a specialized manufacturer of plastic pipes and sheets.

HDPE Water Pipe Black Color
HDPE Water Supply Pipe are primarily made from PE resin as the main raw material. PE Water Supply Pipe is formed through processes such as extrusion, sizing, cooling, and cutting. Polyethylene Water Supply Pipe is manufactured using
read more
HDPE Water Pipe
HDPE Water Supply Pipe are primarily made from PE resin as the main raw material. PE Water Supply Pipe is formed through processes such as extrusion, sizing, cooling, and cutting. Polyethylene Water Supply Pipe is manufactured using
read more
HDPE Double Wall Corrugated Pipe
Double Wall Corrugated PE Pipe is a type of plastic pipe made primarily from high-density polyethylene. Corrugated Driange HDPE Pipe is co-extruded by inner and outer extruders in a single molding process, featuring a smooth inner wall, a
read more
HDPE Reinforced Screw Pipe
HDPE Reinforced Screw Pipe incorporates U-shaped steel strips bonded with PE material, significantly enhancing the ring stiffness without increasing costs. Compared to spiral-wound pipes and Krah pipes of the same weight, Steel Belt HDPE
read more
PE RT Floor Heating Pipe
Floor heating is a new and ideal heating method. Low-temperature hot water radiant floor heating uses low-temperature hot water as the heat medium, which is circulated through heat-resistant pipes (such as PE-RT) embedded in the floor to
read more
PPR Water Pipe
PPR Pipe (Random Copolymer Polypropylene)is a third-generation specialized material for polypropylene piping, also known as Type 3 Polypropylene. PPR Plastic Pipe overcome the drawbacks of homopolymer polypropylene, offering excellent
read more

Why choose us

Our Certificate
ISO9001; ISO14001;ISO45001;Top 10 Chinese Sheet Brands; Top 10 Chinese Pipe Brands; Certificate of Enterprise Integrity Management System; After-sales Service Compliance Certificate; Certificate of Hebei Provincial Industrial Enterprise R&D Institution; Certificate of International Standards Compliance; Certificate of High-Tech Enterprise

Production Market
Our products have been exported to more than 30 countries, such as America, England, Canada, Korea, Australia, Singapore, Malaysia, Thailand and so on.

Our service
Baoding Lida Plastic Industry Co., Ltd. is committed to providing more than just quality products to our customers, as well as offering a range of value-added services including technical support and timely response to our customers' daily needs. We're collaborating with you every day to not just meet your highest expectations, but to help you exploit new market continually.

Size:

Polyethylene (PE100) Pipe Specifications for Water Supply

Nominal Outside Diameter(mm)	Wall Thickness (mm)	Nominal Pressure (MPa)	Nominal Outside Diameter (mm)	Wall Thickness(mm)	Nominal Pressure (MPa)
32	3.0	1.6	250	18.4	1.25
40	3.7	1.6	250	22.7	1.6
50	4.6	1.6	280	10.7	0.6
63	4.7	1.25		13.4	0.8
63	5.8	1.6		16.6	1.0
75	4.5	1.0		20.6	1.25
	5.6	1.25		25.4	1.6
	6.8	1.6	315	12.1	0.6
90	4.3	0.8		15.0	0.8
	5.4	1.0		18.7	1.0
	6.7	1.25		23.2	1.25
	8.2	1.6		28.6	1.6
110	4.2	0.6	355	13.6	0.6
	5.3	0.8		16.9	0.8
	6.6	1.0		21.1	1.0
	8.1	1.25		26.1	1.25
	10.0	1.6		32.2	1.6
125	4.8	0.6	400	15.3	0.6
	6.0	0.8		19.1	0.8
	7.4	1.0		23.7	1.0
	9.2	1.25		29.4	1.25
	11.4	1.6		36.3	1.6
140	5.4	0.6	450	17.2	0.6
	6.7	0.8		21.5	0.8
	8.3	1.0		26.7	1.0
	10.3	1.25		33.1	1.25
	12.7	1.6		40.9	1.6
160	6.2	0.6	500	19.1	0.6
	7.7	0.8		23.9	0.8
	9.5	1.0		29.7	1.0
	11.8	1.25		36.8	1.25
	14.6	1.6		45.4	1.6
180	6.9	0.6	560	21.4	0.6
	8.6	0.8		26.7	0.8
	10.7	1.0		33.2	1.0
	13.3	1.25		41.2	1.25
	16.4	1.6		50.8	1.6
200	7.7	0.6	630	24.1	0.6
	9.6	0.8		30.0	0.8
	11.9	1.0		37.4	1.0
	14.7	1.25		46.3	1.25
	18.2	1.6		57.2	1.6
225	8.6	0.6	710	27.2	0.6
	10.8	0.8		33.9	0.8
	13.4	1.0		42.1	1.0
	16.6	1.25		52.2	1.25
	20.5	1.6	800	30.6	0.6
250	9.6	0.6		38.1	0.8
	11.9	0.8		47.4	1.0
	14.8	1.0		58.8	1.25

Product Technical Data Sheet

Item	Technical Indicators
Hydrostatic Strength at 20℃	No Rupture, No Leakage
Hydrostatic Strength at 80℃	No Rupture, No Leakage
Elongation at Break	≥350%
Longitudinal Reversion	≤3%
Oxidation Induction Time	≥20min

Benefits of HDPE Pipes

The benefits of HDPE pipe systems stem from their physical properties, which allow them to outperform traditional piping materials in many applications. Some of the most notable benefits include:

Durability:
HDPE pipes are resistant to chemicals, abrasions, impacts, and environmental stressors like extreme weather conditions.

Flexibility:
HDPE pipe systems’ flexibility makes them ideal for use in regions prone to seismic activity or shifting soil conditions, as they can bend without breaking.

Corrosion Resistance:
Unlike metal pipes, HDPE pipe installations are non-corrosive, which is a significant advantage in water and wastewater systems where corrosion can lead to contamination and system failure.

Cost-Effectiveness:
While the initial cost of HDPE pipes may be higher than some alternatives, their longevity and low maintenance requirements make them more economical in the long run.

Environmental Sustainability:
HDPE pipe is fully recyclable, contributing to its popularity as an environmentally friendly option. Recycled HDPE can be repurposed into new pipes or other products, reducing waste in landfills.

Versatile Applications
HDPE pipe systems are used in a wide range of industries, from residential water supply to industrial chemical transport. Their ability to resist wear and tear makes them suitable for transporting gases, slurries, and water, both potable and wastewater.

Applications Of HDPE Water Pipe

HDPE pipes are used immensely for several applications due to their unique features such as high flexibility, corrosion resistance, and so on. Following are the important applications of HDPE pipes:

Water Supply
HDPE pipes are made of food-grade polyethylene virgin material, making it safe for the transfer of potable water. These pipes are used in private and public water supply systems due to their high resistance to corrosion, wear and tear, and chemical exposure.

Sewerage and Drainage
HDPE pipes are often used in sewerage and drainage systems due to their high resistance to chemicals and corrosiveness. These pipes are sturdy enough to withstand high pressure.

Mining
HDPE pipes are also best-suited and ideal for use in mining applications, such as slurry transport and process water transport, etc. Since HDPE pipes are resistant to abrasion and impact, they are ideal for use in harsh environments.

Gas Distribution
HDPE pipes are generally used in gas distribution systems as they are highly resistant to chemicals and UV radiation. Due to flexibility, these pipes are the best for use in areas with soil movement and seismic activity.

Cable Protection
HDPE pipes are used to protect underground electrical and telecommunications cables due to high resistance to chemical exposure and impact.

Chemical Transportation
Being chemical-resistant, HDPE pipes are used in the transport of chemicals and hazardous materials.

After Sales Service

Packaging : Roll plastic bag for pipe ,put fittings into nylon bags then out of carton
Shipping:For samples order ,we support transfer by international express,such as FEDEX,DHL,TNT or EMS;
Delivery : Within 2weeks after receiving deposit

FAQ

Q: Are you manufacture?

A: YES we are manufacturer.

Q: Do you provide free sample?

A: YES, we supply you free sample within one day.

Q: What is your deivery time?

A: Our delivery time is normally 7 to 15 days after deposit.

Q: What is the payment terms?

A: We accept T/T, L/C at sight, PayPal & West union.
Yes we have professional engineer teams. We can deisgn and produce special products According to customers' request.

We're well-known as one of the leading pe pipe manufacturers and suppliers in China. Please feel free to wholesale high quality pe pipe made in China here from our factory. Contact us for more details.
